PRICE REFERENCE CHART
*All price on the table is in US dollars.
Non-Pro Non-Disc
| Hub Brand | Price | |
| With High TG Surface | With Grooved Gaphene Surface | |
| Novatec | 460~680 | 510~740 |
| DT SWISS 350 | 580~720 | 640~780 |
| Hope | 720~860 | 780~920 |
| DT SWISS 240S | 750~890 | 810~950 |
| Chris King R45 | 1000~1140 | 1060~1200 |
| Carbon-Ti | 890~1030 | 950~1090 |
| Extralite | 1140~1280 | 1200~1340 |
DIFFERENCES BRIEFINGS FOR GROOVED GRAPHENE SURFACE / HIGH TG SURFACE
Non-Disc Grooved Graphene Surface
Graphene Brake Track : Graphene added to the rim brake track allows for greater resistance to overheating with improved heat dissipation and reduced temperature accumulation during heavy braking. The grooved track helps evacuate trapped moisture between pad and rim in the wet, and brings more resistance when conditions are dry so less force at the lever is required.
Non-Disc High TG Surface
High TG Surface: Rim Brake 700C road rims use an advanced High TG resin system with a layer of graphene to help dissipate heat. The braking power and reliability is significantly improved over a basalt braking surface.
If you are going for non-disc wheels applying the most advanced technologies but with a much better price, the grooved graphene surface stand out for you.
Or if you have a limited budget, wanting to have a pair of non-disc wheels competent to deliver decent performance on major occasions, the most cost-effective high TG surface support you there making your dream come true.
RIM LIST
700C(CLINCHER)
| Model | Depth(mm) | External Width (mm) |
|---|---|---|
| R25 | 25 | 25 |
| R35 | 35 | 25 |
| R45 | 45 | 25 |
| R55 | 55 | 25 |
| R65 | 65 | 25.85 |
| R88 | 88 | 26.54 |
| AR36 | 36 | 28 |
| AR46 | 46 | 28 |
| AR56 | 56 | 30 |
| Model | Depth(mm) | External Width (mm) |
|---|---|---|
| R25T | 25 | 25 |
| R35T | 35 | 25 |
| R45T | 45 | 25 |
| R55T | 55 | 25 |
| R65T | 65 | 25.85 |
| R88T | 88 | 26.54 |
HUB SPECIFICATION
*Hub weight: Take front 100mm QR/rear 130mm QR for reference
Carbon-Ti (non-disc)
Weight
220gColor
.png)
Front size
- 100mm QR
Rear size
- 130mm QR
Description
ROAD rear hub with oversized Al7075-T6 CNC machined body and axle, external bearing preload system, Al7075-T6 free wheel Shimano/SRAM 10-11s compatible. Several anodized colours or mirror polished available. Made in Italy.
Extralite SP (non-disc)
Weight
177gColor
Front size
- 100mm QR
- 15*100mm
- 12*100mm
Rear size
- 130mm QR
- 135mm QR
- 12*142mm
Description
Alternatively, consider CyberFront SL and CyberRear SL that offer the easiness of externally mounted standard elbow spokes and the widest possible camber of all spoke flanges.CyberFront SP features the widest possible spoke camber to offer higher lateral stiffness.It fits most road forks however few makers introduced bulge legs that reduce hub clearance. For that reason also we have introduced CyberFront SP-X that is still able to achieve that same high lateral wheel stiffness allowing a sensibly higher spoke tension.
Chris King R45 (non-disc)
Weight
317gColor
Front size
- 100mm QR
Rear size
- 130mm QR
Description
Alternatively, consider CyberFront SL and CyberRear SL that offer the easiness of externally mounted standard elbow spokes and the widest possible camber of all spoke flanges.CyberFront SP features the widest possible spoke camber to offer higher lateral stiffness.It fits most road forks however few makers introduced bulge legs that reduce hub clearance. For that reason also we have introduced CyberFront SP-X that is still able to achieve that same high lateral wheel stiffness allowing a sensibly higher spoke tension.
DT SWISS 240s(non-disc)
Weight
321gColor
Front size
- 100mm QR
Rear size
- 130mm QR
Description
Swiss precision engineering, machining and assembly together with clever detail solutions have made of the 240 what it is today: A legend. Featuring the latest refinements the 240 hubs are extremely lightweight and extremely durable. The Ratchet System is the best solution for a freewheel system, since it can transfer high loads while being super light. Just what athletes want: Perfect transmission of their power and the reliability allowing them to focus on the ride.
DT SWISS 350 (non-disc)
Weight
375gColor
Front size
- 100mm QR
Rear size
- 130mm QR
Description
description: Whoever is looking for the most affordable high performance hubs available, should take a very close look at the 350 hub line-up. The same performance as its even higher end cousins comes with slightly less weight optimized parts to offer the same reliability at a much lower cost. Being available in all standards and for any application, the 350 hub is for those who maybe like to ride the trails a little more than drooling over catalogs and specs.
Hope RS4 (non-disc)
Weight
394gColor
Front size
- 100mm QR
Rear size
- 130mm QR
Description
Sealed Stainless Steel cartridge bearings; Hub shell machined from forged aluminium billet; Unsurpassed reliability; Reduced drag ratchet mechanism; 44 point engagement (8 deg).
Novatec A291/F482 (non-disc)
Weight
298gColor
Front size
- 100mm QR
Rear size
- 130mm QR
Description
The least expensive but decent value to get you into a carbon wheelset without breaking.
